Bushranger Spartan RZ-C 54" Zero Turn Mower

Bushranger Spartan RZ-C 54" Zero Turn Mower

Regular price $11,599.00 AUD
Regular price $11,899.00 AUD Sale price $11,599.00 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.

Description

The RZ-C is our newest compact solution with BIG results. Manufactured with the same fusion welded tube frame as our bigger zero turns, the RZ-C has the same durability with a lower starting price! The Bushranger RZ-C eats up lawns of all sizes and comes packed with premium features that are all included as standard, and truly make the Bushranger RZ-C stand out from the rest. Features like the bullet proof Kawasaki FR691V V-Twin engine (usually reserved for commercial mowers), safety features like the GT Trac for the best traction on inclines, the easy touch brake system, the foot assist easy-lift deck, an ergonomic cockpit and huge fuel tanks will have you happily and safely mowing for hours without having to stop until the jobs done. All Spartan Mowers have an Xtreme Turf Flow (XTF) deck fabricated from 7 gauge steel, not just the top end models. Check out the competition and see the difference for yourself. No light duty decks here! This enhanced deck system comes standard on ALL models and the RZ-C is fitted with a 4" deep version of the deck which allows it to manoeuvre easily in tight spaces. The Bushranger RZ-C series ZTR’S are built and perform like a commercial grade mower but at an affordable price.

Features



Kawasaki FR691V premium and commercial grade V-Twin engine.
TUFF TORQ 300 series serviceable transaxles.
Ground speed infinitely variable up to 0-12.9 kph.
GT-Trac for precision traction, balance and control on inclines.
18.9 litres fuel capacity.
Ogura electric PTO Clutch.
Fabricated heavy-duty 1.5" x 3" fusion welded tube frame.
Front caster forks are fabricated using 17/64" steel.
Heavy-duty fabricated steel, 4” deep deck.
Vibration control deck system (on 54" cut deck models only).
Cast aluminium 1" shaft with twin double sealed bearings.
Long lasting deck belts are designed with large idler pulleys to minimize wear.
ZTR is perfectly balanced with low centre of gravity.
Foot operated parking brake.
Control panel with LCD display, which contains at the push of a button a tachometer, engine hour meter, mowing hours meter, battery voltage, a countdown timer for engine oil replacement and a clock.
Keyless starting - Push-start keypad, featuring a personalised code to start.
12v outlet with plug and play wiring system.
Cup holder.
Mid-back bolstered seat.
Easy access for servicing with a removable floorpan.
Rubber floor mat.
20" drive tyres (New - Carlisle turf armour tyres).
13" front caster tyres.
Solid anti-scalping wheels with grease nipples on deck.


Warranty Information

Domestic Warranty
3 Years or 300 Hours Domestic Warranty
Commercial Warranty
3 Years or 300 Hours Commercial Warranty
Hire/Rental Warranty
No Hire / Rental Warranty

Miscellaneous

Blade(s)
3

Dimension Specs

Dry Weight
343.7 kg
Height
46" (1168.4 mm)
Length
82" (2082.8 mm)

Zero Turn Mower Specs

Ground Speed - Forward
Infinitely variable up to 0-12.9 kph
Brakes
Foot-operated parking brake
Caster Tyres
13 x 6.50- 6, smooth tread
Tyres - Drive
20" Carlisle turf armour tyres
Seat
Mid-back bolstered seat
Construction
Mainframe 1.5” x 3” (38.1 mm x 76.2 mm) powder coated fusion welded tube frame. Front caster wheels mounted with commercial duty greaseable roller bearings on each wheel
Hour Meter
Standard
Controls
Hand-operated choke, throttle, keyless starting, electric mower clutch, foot pedal parking brake
Cup Holder
Yes
Deck System
Side-Discharge: 54" (1372 mm) cut. (3) Blades, Includes deck-mounted anti-scalp wheel(s) to improve flotation in rolling and uneven terrain
Deck Lift
Foot operated / shock assist
Deck Construction
4” Deep, Fabricated 7 Gauge with 7 gauge spindle mounts and 9/16" impact bar
Blade Drive
V-belt drive to spindles with electric clutch. Spring tension idler pulleys for extended belt life
Spindles
Cast aluminium 1" shaft with twin double sealed bearings
Drive System
V-belt drive from engine crankshaft
Discharge Chute
High density, rubberised
Steering
Twin-lever steering provides independent control of each drive wheel. Speed, forward, reverse, brake, and turns are all controlled with hand-operated controls

Engine and Fuel Specs

Engine
Kawasaki FR691V
Type
Air cooled, 90-degree V-Twin, normally aspirated petrol engine
Horsepower
23.0 hp (17.2 kW) @ 3600 rpm (Please Note: Horsepower rating as tested to SAE J1995 Standards)
Cooling
Air cooled. Flywheel fan
Fuel
Unleaded fuel - maximum of 10% ethanol in fuel (see engine manufacturers specifications)
Fuel Filter
Replaceable, automotive-type
Oil Filter
Spin-on engine oil filter / Total oil capacity 2.1 litres with filter
Air Filter
Cartridge air filter
Fuel Capacity
18.9 Litres
Governor
Mechanical

Hydrostatic Drive System Specs

Hydrostatic Drive System
Dual hydrostatic TUFF TORQ 300 series transaxles

Cutting Dimensions

Cutting Widths
54" (1372 mm) cut side discharge
Cutting Height(s)
1” to 4.5" (25.4 mm to 114.3 mm)
